Apple Pay Developer Guidelines

1. Introduction

This guide provides detailed instructions on integrating Apple Pay for web and in-app applications, including domain verification, payment processing, and security compliance.

2. Setup & Integration

We support Apple Pay for e-commerce web and iOS applications. The following diagrams show all actions on Bonum and Enterprise user side:

1. If you need web application integration:

2. If you need in-application integration:

3. Web App Integration

3.1 Domain Verification

1.INSTRUCTION

Domain verification is a required step for enabling Apple Pay on your website. It confirms that you own the domain and are authorized to accept payments via Apple Pay.
The process involves placing a special verification file, provided by us (Bonum PSP), on your domain's web server and notifying us to verify it with Apple.

2.PREREQUISITES

Before proceeding, ensure you have:
- Access to your web server or hosting environment to upload files.
- A valid domain name that matches the one used for your Apple Pay integration.

3. STEPS FOR DOMAIN VERIFICATION

Step 1: Obtain the Verification File
- Bonum will provide this file (File name is apple-developer-merchantid-domain-association)

Step 2: Place the File on Your Web Server
1. Create the required directory:
On your web server, create a directory named .well-known in the root directory of your domain (if it doesn’t already exist).

Example Path:
https://yourdomain.com/.well-known/

2. Upload the file:
Place the downloaded apple-developer-merchantid-domain-association file inside the .well-known directory.
Ensure the file is accessible publicly via the following URL:
https://yourdomain.com/.well-known/apple-developer-merchantid-domain-association

3. Content-Type:
The Apple Pay web merchant validation file must be served with a Content-Type of text/plain when accessed via a browser or HTTP request.

4. Verify file placement:
Open a browser and navigate to the file's URL. You should see the contents of the file displayed as plain text.

Step 3: Notify Us
- After placing the file, let us be informed by any available communication channels.

Step 4: Domain Verification by Apple
Our system will communicate with Apple to verify your domain. This process usually completes within a few minutes. We will inform merchants once the verification is successful.

4. TROUBLESHOOTING

Issue 1: File Not Found
Cause: The apple-developer-merchantid-domain-association file is not correctly placed in the .well-known directory. Solution: Verify the file path and ensure the file is accessible via its URL.

Issue 2: Access Denied
Cause: Your server has restricted access to the .well-known directory or file.
Solution: Check your server's permissions and ensure the .well-known directory and file are publicly accessible.

3.2 Web App Implementation

APPLE PAY > PSP > Web App

PREREQUISITES

Before proceeding, ensure that you have completed:

Merchant ID (The Merchant ID should have been provided by Bonum PSP)
Merchant Key (The Merchant Key should have been provided by Bonum PSP)
Demo Web App Source apple-pay-example-v1.0.0.zip (Source files should have been provided by Bonum PSP)

APPLE PAY > PSP > Demo Web App Source

A.) DEMO SOURCE FILES

Extract apple-pay-example-v1.0.0.zip file in a folder:

index.html - The frontend with the Apple Pay button and JavaScript integration.
server.js - The backend server (Node.js with Express) that handles Apple Pay merchant validation and payment processing.
package.json - Lists dependencies needed for your backend (e.g., express, node-fetch).
package-lock.json - Automatically generated to lock dependency versions.

Web App > Frontend Integration

B.) INDEX.HTML

Note: Apple Pay button implementation

Web App > Frontend Integration

C.) INDEX.HTML

Note:
1.Replace “REPLACE_YOUR_MERCHANT_IDEN_TIFIER_HERE”with your merchant ID.
2. "total” represents the amount to be charged. To break down the payment details, use "lineItems".
3. Create a new Apple Pay session.

function startApplePaySession() {
// Merchant-specific information
const merchantIdentifier = 'REPLACE_YOUR_MERCHANT_IDENTIFIER_HERE'; // Replace with your actual merchant ID

// Payment request details
const paymentRequest = {
  countryCode: 'MN', // Country code for Mongolia
  currencyCode: 'MNT', // Mongolian Tugrik
  supportedNetworks: ['visa', 'masterCard', 'amex'], // Supported card networks
  merchantCapabilities: ['supports3DS'], // Security capabilities
  displayName: 'Your Merchant Name', // Name displayed on the payment sheet
  total: {
    label: 'Your Merchant Name', // Total summary label
    amount: '100', // Total amount (in whole numbers for MNT (100.00 is invalid, 100 - is valid))
  },
  lineItems: [ //optional
    { label: 'Product A', amount: '200' },
    { label: 'Discount', amount: '-100' },
  ],
  applicationData: btoa(merchantIdentifier), // Base64 encoded merchant ID
};

// Ensure amount is a whole number for Mongolian Tugrik (MNT)
if (paymentRequest.currencyCode === 'MNT' && !Number.isInteger(Number(paymentRequest.total.amount))) {
  alert('Amounts in Mongolian Tugrik (MNT) must be whole numbers without decimal points.');
  return;
}

// Create a new Apple Pay session
const session = new ApplePaySession(3, paymentRequest);

// Step 3: Validate the merchant during the payment session
session.onvalidatemerchant = async (event) => {
  try {
    const response = await fetch('https://psp.bonum.mn/api/merchant/validate', {
      method: 'POST',
      headers: { 'Content-Type': 'application/json' },
      body: JSON.stringify({ validationURL: event.validationURL }),
    });
    const merchantSession = await response.json();
    session.completeMerchantValidation(merchantSession);
  } catch (error) {
    console.error('Merchant validation failed:', error);
    session.abort();
  }
};

Web App > Frontend Integration

D.) INDEX.HTML

Note: Handle payment authorization.

// Step 4: Handle payment authorization
session.onpaymentauthorized = async (event) => {
    const token = event.payment.token;

    try {
      //frontend will send token to its backend. merchant can customize to their needs.
      const response = await fetch('http://localhost:3000/api/payment/authorize', {
        method: 'POST',
        headers: { 'Content-Type': 'application/json' },
        body: JSON.stringify({ token, orderId: 'REPLACE_ORDER_ID_HERE' }),
      });
      const result = await response.json();

      // merchant backend response parsing, customize to your needs.
      if (result.success) {
        session.completePayment(ApplePaySession.STATUS_SUCCESS); //mandatory
        ///alert("Payment succeeded: $ {result.description}");
      } else {
        session.completePayment(ApplePaySession.STATUS_FAILURE); //mandatory
        // alert("Payment failed: $ {result.description}"");
      }
    } catch (error) {
      console.error('Error processing payment:', error);
      session.completePayment(ApplePaySession.STATUS_FAILURE);
      alert('Unexpected error occurred while processing payment.');
    }
  };

  // Step 5: Handle payment cancellation
  session.oncancel = () => {
    console.log('Payment was canceled by the user.');
    alert('Payment was canceled.');
  };

  // Step 6: Begin the session
  session.begin();
}

Web App > The backend Integration

E.) SERVER.JS

Note: Handle payment authorization and process the payment.
Replace “REPLACE_YOUR_MERCHANT_KEY"with your merchant key.

const express = require('express');
const bodyParser = require('body-parser');
const axios = require('axios');
const cors = require('cors');
const app = express();
const PORT = 3000;

// Allow specific origins (replace "http://example.com" with your frontend's URL)
app.use(cors({
  origin: 'https://psp.bonum.mn', // Allow this specific origin
}));

// Middleware: Parses incoming JSON request bodies
app.use(bodyParser.json());

/**
 * Endpoint to process payment authorization.
 * The client sends a token and an orderId, which are forwarded to the PSP (Payment Service Provider).
 */
app.post('/api/payment/authorize', async (req, res) => {
  const { token, orderId } = req.body;

  // Step 1: Validate incoming request data
  if (!token || !orderId) {
    return res.status(400).json({
      success: false,
      message: 'Missing token or orderId',
    });
  }

  try {
    // Step 2: Forward the payment data to the PSP
    const response = await axios.post(
      'https://psp.bonum.mn/api/payment/process', // PSP endpoint URL
      {
        token,          // Payment token received from Apple Pay
        order_id: orderId, // Merchant invoice/order id
      },
      {
        headers: {
          'Content-Type': 'application/json',
          'x-merchant-key': 'REPLACE_YOUR_MERCHANT_KEY', // Replace with your actual merchant key
        },
      }
    );
        console.log('resp', response.data);
    // Step 3: Respond to the client with the PSP's response
    res.json({
      success: response.data.success,       // Indicates if the payment was successful
      status_code: response.data.status_code, // PSP's status code for the operation
      orderId: response.data.orderId,       // The order ID provided in the response
      description: response.data.desc,      // Additional information about the payment
    });
  } catch (error) {
    console.error('Error processing payment:', error.message);

    // Step 4: Handle errors from the PSP or network issues
    if (error.response) {
      // Errors returned directly by the PSP
      return res.status(error.response.status).json({
        success: error.response.data.success,       // Whether the PSP recognized the payment as successful
        status_code: error.response.data.status_code, // PSP-specific error code
        orderId: error.response.data.orderId,       // Order ID (if available)
        description: error.response.data.desc,      // PSP-provided error description
      });
    }

    // Step 5: Handle unexpected or generic errors (network, server, etc.)
    res.status(500).json({
      success: false,
      status_code: 500,
      orderId,                           // Original order ID for traceability
      description: 'Unexpected error occurred while processing payment.', // Generic error message
    });
  }
});

// Start the Express server
app.listen(PORT, () => {
  console.log("Server is running on http://localhost:" +PORT);
});

Web App > The backend integration

F.) CHECK PAYMENT

Note: You can use the /api/payment-log/read API for handling any payment failure cases.
Replace “REPLACE_YOUR_MERCHANT_KEY" with your merchant key.
This API call should be executed on your backend.

func checkPaymentByOrderId(orderId: String) {

  let manager = AFHTTPSessionManager()
  manager.requestSerializer = AFJSONRequestSerializer()
  manager.responseSerializer = AFJSONResponseSerializer()
  manager.responseSerializer.acceptableContentTypes = manager.responseSerializer.acceptableContentTypes?.union(["application/json"])
  //TODO: set Merchant Key here. Bonum will provide Merchant Key.
  manager.requestSerializer.setValue("SET-YOUR-MERCHANT-KEY-HERE", forHTTPHeaderField: "x-merchant-key")


  //Demo URL. Note: This URL charges the bank transaction. Please use small amount when you test
  var urlString = "https://testpsp.bonum.mn/api/payment-log/read"
  //Production URL. When you push your Build to the production
  //var urlString = "https://psp.bonum.mn/api/payment-log/read"

  urlString = urlString + "?order_id=" + orderId
  // Convert the JSON object to a JSON string
  print("API Url: \(urlString)")

  manager.get(urlString,
              parameters: nil,
              headers: nil, progress: { progress in
      print("Download progress: \(progress.totalUnitCount)")
  }, success: { task, responseObject in
      print("Transactions for Order ID: \(orderId)")
      print("GET response: \(responseObject ?? "No response")")
  }, failure: { task, error in
      print("Error on GET request: \(error.localizedDescription)")
  })
}

Web App > The backend integration

G.) CHECK PAYMENT RESPONSE

Note: "success": false indicates that the transaction failed for some reason.

Note: "success": true indicates that the transaction was processed successfully.

[
    {
      "merchant_order_id": "9876543",
      "amount": 5000,
      "success": false,
      "createdAt": "2025-01-24T03:22:03.135Z"
    },
    {
      "merchant_order_id": "9876543",
      "amount": 5000,
      "success": true,
      "createdAt": "2025-01-24T03:22:03.135Z"
    }
]

4. IOS App Integration
